M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable
100pcs
MOQ
$2-$3
Price
M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Rigoal
Certification: CE,RoHS
Model Number: M8 4pins connector
Payment & Shipping Terms
Packaging Details: PE bag and carton
Delivery Time: Based on the order quantities
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 Piece/Pieces per Month base on the cable length
Specifications
Coupling: Threaded Coupling
Termination: Solder
Shell Material: Zinc Alloy With Nikelplate
Mating Cycle: 500times
Insert Material: PA66+%30GF
Teperature Range: -25℃---+85℃
Contact Material: Copper(silverplated/gold)
Rated Current: 4A
Degree Of Protection: IP67
Contacts: 3 4 5 6 8 12pins
Product Description

M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable



Product description

The M8 is a common connector at the field level, although to date only for the transmission of signals.

M8 Connector, Standard Circular Connectors, Wire-to-Wire, 4 Position, Sealable, Wire & Cable, 3A Contact Current Rating (Max).

A wide range of M8 connector variations available in IP67/IP68 cable mount and panel mount options used in demanding industrial applications.



Quick Details
Type:M8
Application:Automotive, Sensor or Automation
Gender:male/female
Product name:M8 A coding R/A female to female waterproof cable

Rated current:4A
Contacts:3,4,5,6 8pins are available
Coupling:Threaded coupling
Shielding:un-alaibable
IP degree:IP67/IP68



Description
Anti-vibration locking screw design
RoHS & REACH Compliance

There is PG7 and PG9 for choose,PG7 subitable OD4-6mm cable,PG9 suitabble OD6-8mm cable

Electrical Data
Rated voltage:60V
Insulation resistance:100MΩ
Contact resistance:≤5mΩ
Ambient temperature:-20°C~+80°C

Standard:IEC61076-2-101



Material
Overmold:Transparent TPU
Insert:TPU+GF

Material of Housing: Brass Nickel Plated

Cable Jacket: PVC or PUR

Wire Gauge: 24AWG or 26AWG

Material of Insert: PA+GF, UL9V_0

Material of Contacts: Male brass, female phosphor Bronze, Gold Plated



Core Insulation of Connecting Leads  PVC, PETP, diameter 1.0 mm to 1.55 mm
Protection Class IP 67 (total protection from dust and temporary immersion in water - up to 1 meter for up to 30 min)
Contact Material Cu Sn
Contact Surface Material  Gold
Contact Bearer Material  Polyamide
Housing Material  Polyamide
Coupling Nut Material  Zn Ai/Ni
O-Ring Viton/NBR
Operating Temperature -25 C to + 70 C (-13 F to 158 F)
Type of Termination Pin Penetration



M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable 0M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable 1

M8 Waterproof IP68 4 Pins Female To Male Molded Automotive Connector With Cable 2

Packaging & Shipping

Usually standard size 38*32*32cm/CTN,1000pcs/CTN

approval customized based on customers' requirements

MOQ: 100pcs each item

Delivery time: 5-7days after the payment received

Shipment: by Express,by Air, by Sea

Payment terms: 100% TT in Advance

Payment method: T/T, Western Union, Paypal



Company Information

         Rigoal was founded in 2013, and devoted ourselves to be the high quality & efficient manufacturer. We specialized in producing waterproof cables & waterproof connectors such as M8, M12, M16, M23, D-SUB. Mainly applied in sensors, industrial equipment, transportation facilities, medical devices, LED displays, outdoor advertisements, communication devices,wind energy devices, vessel industrial and Surrounding the car electronics industry and so on ,they are equivalent to Phoenix, Binder, Lumberg and Molex etc.

         Our philosophy and purpose is: Customer Foremost, Service First,Quality first.Our products mainly exported to all over the world.And get a high degree approval and recognition from our customers.

Sincerely to work with you together in the near future.
