M8 Waterproof Connector Compatible 8pins Panel Mount Circular Connector With Tail
Product description
M8 Series Threaded, Panel Mount, Bulkhead - Rear Side Nut, IP67 - Dust Tight, Waterproof Circular Connectors TE Connectivity AMP Connectors The M8 connector system provides a solution that safely and reliably ensures the communication in industrial environments.
These receptacles can be used to connect cables in sensor, actuator or any other application
A variety of sizes and appearances connector to our customer for easy to use and assemble
Quick details
1. M8 panel mount connector
2. Connector locking system is bolted
3. Termination is solder
4. Wire gauge(mm) is 0.25mm²
5. Wire gage(AWG) 24
6. Cable outlet can be 3,5 - 5,0 mm
7. Temperature will from -40° to +85°
8. Contacts 3.4.5.6.8pins avaliable
| Material Data | |
| Contact material | CuZn (brass) |
| Contact plating | Au (gold) |
| Contact body material | PA |
| Housing material | PA |
Electrical values
Rated current (40 °C) :1.5A/4 A
Rated voltage :30V/60 V
Rated impulse voltage :1500 V
Pollution degree :3
Overvoltage category :III
Insulating material group :III
Volume resistivity :≤ 3 mΩ
EMC compliance :not shielded
Degree of protection :IP67
Mechanical operation :> 100 Mating cycles
| Number of Contacts | 3 | 4 | 5 | 6 | 8 |
| Rated voltage | 30V | 60V | |||
| Contact resistance | <5mΩ | ||||
| Insulation resistance | <100mΩ | ||||
| Pollution degree | 3 | ||||
| Temperature range | 25 °C to 85° C | ||||
| Degree of protection | IP 67 when mated | ||||
| Mating times | 100 cycles | ||||
| Wire gauge | 24AWG | 26AWG | |||
| Cable jacket | PVC or PUR | ||||
| Material of housing | Brass Nickel Plated | ||||
| Material of insert | PA+GF UL9V-0 | ||||
| Material of contact | Brass phosohor bronze gold plated | ||||
Product photos
Packsging & Shipping
1.Our general packing: PE bag and PE bag contons. General Carton size:40*30*30cm
2.Customized according to customer's request
M8 connector can be used a wide fields like LED, Automation, Sensor, mechanise equipment etc.
• LED lighting , white light , color light etc
• Low current equipement
• Connector be used in narrow environment
• Communication equipement
• Lighting harness
