IP67 M8 Waterproof Connector

100
MOQ
negotiable
Price
IP67 M8 Waterproof Connector
Features Gallery Product Description Request A Quote
Features
Specifications
Ambient Temperat: -20/- 40℃~+80℃
Connector Contacts: Brass With Gold Plated
Connector Insert: TPU/PA
Contact Resistance: ≤5mΩ
Shielding: Unavailable
Standard: IEC 61076-2-104
Certificate: UL/CE/ROHS/IP67/REACH/IP68
Coupling Nut/Screw: Zinc Alloy With Nickel Plated
Colour: Black
Gender: Female
Mounting Type: Right Angled
High Light:

6Pins M8 Waterproof Connector

,

REACH M8 Waterproof Connector

,

RIGOAL Waterproof Male Female Connector

Basic Infomation
Place of Origin: Shen zhen,China
Brand Name: RIGOAL
Certification: CE,Rohs
Model Number: MA08F**HD**RAXXXXXX
Payment & Shipping Terms
Packaging Details: m8 3pin male ip67 waterproof panel mount pcb connector 1.Our packaging:each pcs in one PE bag, then put in a small carton. 2.According to customer request.
Delivery Time: 14
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000
Product Description

 Waterproof IP67 Male Female Straight 90 Degree 6Pin M8 Circular Connector With Shield Wire

Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Finecables(FC)
Model Number:
MA08F**HD**RAXXXXXX
Type:
M8 Molded Cable Connectors
Application:
Sensor Industrial Automation
Gender:
Female
Connector Series:
M8 Waterproof Connector
Ambient Temperature:
-20/- 40℃~+80℃
Connector Insert:
TPU/PA
Connector Contacts:
Brass with Gold Plated
Connector Overmold:
TPU
Coupling Nut/Screw:
Zinc Alloy with Nickel Plated
Contact Resistance:
≤5mΩ
Insulation Resistance:
≥ 100M Ω
Mating Endurance:
> 500 cycle
Certificate:
ULs/IP67/REACH/IP68/CE/ROHS







IP67 M8 Waterproof Connector 0IP67 M8 Waterproof Connector 1IP67 M8 Waterproof Connector 2IP67 M8 Waterproof Connector 3

Parameter
Value
Plug body
TPU/Black
Coupling nut
Brass/Nickel
Contact carrier
PA/Black
Pin
Brass/Gold
O-ring
FPM/FKM
IP degree
IP67
Insulation
≥10 9Ω
Forward resistance
≤5mΩ
Rated current
6P 2A
Rated voltage
30V
Pollution degree
3
Temperature range
-40…80 ℃
Mechanical operation
≥100
Maximum cable diameter
5.6mm



Packaging & Delivery
Packaging Details
-- Standard Packing:
Transparent PE Bag.
Carton Size:44.5*36.5*23.5(cm),17.5*14.4*9.3 Inch

-- OEM Package Available.
Port
HongKong,ShenZhen,SheKou,ShangHai,YanTian,etc
