M8 Male 8pins Panel Mount Solder Waterproof IP67 Soldering Socket Mount Connector
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Rigoal
Certification: CE,RoSH
Model Number: M8 panel mount connector
Payment & Shipping Terms
Packaging Details: PE bag and Cartons
Delivery Time: 7-10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 per week
Specifications
Connector Design: Male Connector
Termination: Solder
Wire Gauge (mm): 0,25 Mm²
Contacts: 8poles
Cable Outlet: 3,5 - 5,0 Mm
Upper Limit Temperature: 85 °C
Lower Limit Temperature: -40 °C
Rated Current (40 °C): 1.5 A
Rated Voltage: 30 V
Rated Impulse Voltage: 1500 V
Volume Resistivity: ≤ 3 MΩ
Degree Of Protection: IP67
Product Description

M8 Male 8pins Panel Mount Solder Waterproof IP67 Soldering Socket Mount Connector



Product description

1. M8 panel mount connector female 4pins PCB connector

2. Connector locking system is bolted

3. Termination is solder

4. Wire gauge(mm) is 0.25mm²

5. Wire gage(AWG) 24

6. Cable outlet can be 3,5 - 5,0 mm

7. Temperature will from -40° to +85°

8. Contacts 3.4.5.6.8pins avaliable



Electrical values

Rated current (40 °C) : 1.5 A

Rated voltage : 30V

Rated impulse voltage :1500 V

Pollution degree :3

Overvoltage category :III

Insulating material group :III

Volume resistivity :≤ 3 mΩ

EMC compliance :not shielded

Degree of protection :IP67

Mechanical operation :> 100 Mating cycles



IP Grade IP67 Plastic
Housing Engineering Thermoplastic Flammability rating UL 94V-0.
Contacts Copper Alloy
Plating Gold plating over nickel in contact
Shield Brass with nickel plated
Coupling Nut M8 x 1 Brass With Nickel Plated
Cable UL 2464 22AWG, OD 5.4mm, Color Black
Current Rating 3A (2 to 5Pin), 1.5A (6 to 8Pin)
Rated Voltage  50V DC (3 to 5Pin), 30V DC (6, 8Pin)
Rated current (40 °C)  4 A
Rated voltage  60 V
Rated impulse voltage  1500 V
Pollution degree  3
Overvoltage category  III
Insulating material group  III
Volume resistivity  ≤ 3 mΩ
EMC compliance  not shielded
Degree of protection  IP67
Mechanical operation  > 100 Mating cycles



Number of Contacts 3 4 5 6 8
Rated voltage 30V 60V
Contact resistance <5
Insulation resistance <100mΩ
Pollution degree 3
Temperature range 25 °C to 85° C
Degree of protection IP 67 when mated
Mating times 100 cycles
Wire gauge 24AWG 26AWG
Cable jacket PVC or PUR
Material of housing Brass Nickel Plated
Material of insert PA+GF UL9V-0
Material of contact Brass phosohor bronze gold plated
