4P Female M8 Waterproof Connector PCB Straight Pressure Transmitters
4P Female M8 Waterproof Connector PCB Straight Pressure Transmitters
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Shen zhen,China
Brand Name: RIGOAL
Certification: CE,ROHS
Model Number: m8 connector
High Light:

250V M8 Waterproof Connector

,

4P M8 Waterproof Connector

,

PCB Mount Circular Connector

Payment & Shipping Terms
Specifications
Pins: 4p
Number Of Positions: 2 / 3 / 4 / 5 / 6 / 8 / 12 / 17 PIN
Mounting Type: PCB Mount / Panel Mount / Cable
Mounting Feature: Front Mount / Back Mount / 4 Hole Flange
Temperature Range: -25°C ~ + 85°C
Jacket Material: PVC / PUR
Degree Of Protection: IP67 / IP68
Name: 250V Waterproof Connector
Product Description

Pressure Transmitters 4P Female M8 Connector PCB Straight Waterproof Connector



Technical Date



Standard IEC61076-2-101
Rated current 4A 4A 4A 2A 1A
Rated voltage 250V 250V 60V 30V 30V
Operating Temperatur -25℃~85 ℃
Degree of protection IP67/IP68
Connector locking system Screw
Mechanical operation >500 mating cycles
Contact resistance ≤10mΩ
Material of connector CuZn
Contact plating Au(gold plating)
Material of connector body PA



4P Female M8 Waterproof Connector PCB Straight Pressure Transmitters 04P Female M8 Waterproof Connector PCB Straight Pressure Transmitters 14P Female M8 Waterproof Connector PCB Straight Pressure Transmitters 24P Female M8 Waterproof Connector PCB Straight Pressure Transmitters 3
