| M8 | |
| Pin | 3 4 5 6 8 pin |
| Coding | A B D coding |
| Rated current | 1.5A for 8 pin; 2A for 6 pin; 3A for 5 pin;4A for 3 4 pin |
| Rated voltage | 30V for 5 6 8 pin; 60V for 3 4 pin |
| Material of connector | CuZn,TPU or PA |
| Cable size | 0.25mm2 for 3 4 5 pin; 0.14mm2 for 6 8 pin |
| M12 | |
| Pin | 3 4 5 8 12 17 pin |
| Coding | A B D X Y S T K L M coding |
| Rated current | 1A for 12 pin/2A for 8 pin/4A for 3 4 5 17 pin |
| Rated voltage | 30V for 8 12 pin/60V for 5 pin/250V for 3 4 17 pin |
| Material of connector | CuZn,TPU or PVC |
| Cable size | 0.34mm2 for 3/4 pin; 0.25mm2 for 5/8 pin; 0.14mm2 for 12/17 pin |
Different combination and color can be chosen
Product Structure detailed
1. Waterproof, moisture-proof, rain proof, sun proof and anti-corrosion
2. Flame retardant, anti-oxidation and environmental protection (all products are from green production lines)
3. Improve the production process: connectors simplify the assembly process of electronic products and also simplify the batch production process
4. Easy maintenance: In case of failure, it is not necessary to clamp and break the cable, electric plastic sleeve, etc., but to unscrew both ends of the waterproof connector. It is very convenient for the maintenance of LED, solar energy, geothermal and other waterproof products
5. Improve the flexibility of design. The use of connectors gives engineers greater flexibility in designing and integrating new products and using components to form systems
Features of M12 connector:
1. Stable and reliable, not affected by the external environment (such as temperature, humidity)
2.Waterproof and moisture-proof, to ensure the stability of the circuit, M12 surface with a layer of coating (anti-corrosion, Oxidation proof)
3.Oil resistance and welding resistance, reduce wiring so that the equipment can be quickly put into operation, good mechanical and electrical performance to ensure stability and reliability, process related operation and function indicator LED can realize fault diagnosis, very little downtime and maintenance time
Applications:
● Sensors, actuators, encoders, motors, industrial cameras, ships and other equipment
● Factory automation process control
● Ship electronics NMEA 2000, rail transit
● Industrial equipment
● EMS circuit board assembly
● Industrial safety grating light curtain
● Packaging label printing equipment
● Fieldbus: DeviceNet, CANopen, Profibus, Ethernet,
● Equipment batteries, semiconductors
● LED outdoor display, outdoor LED lighting
