IP67 Screw Waterproof Electrical Panel Mount Socket M12 Cable Connector
High-performance M12 panel mount connector with superior waterproof protection and versatile mounting options.
Key Features
- M12×1 thread locking mechanism with anti-vibration design
- Quick connect/disconnect coupling for easy installation
- Multiple pin configurations: 2, 3, 4, 5, 8, 12 and 17 positions
- Available in A, B, C, D, K, L, X, S, T coding options
- IP67/IP68 waterproof rating for harsh environments
- Wide temperature range: -25°C to +85°C
- Multiple termination options: solder cup or PCB mount
- Available in panel mount and distribution versions
- Offered as loose pieces or pre-made M12 cables
The M12 Panel Receptacle series provides three mounting choices: PCB Mount, Panel Mount & Cable, with three mounting features: Front Mount, Back Mount, and 4 Hole Flange. Complies with IEC 61076-2-101/104 standard and IP67 protection level.
Technical Specifications
| Specification |
Value |
| Place of Origin |
Shenzhen, China |
| Brand Name |
RIGOAL |
| Model Number |
m12 panel mount solder |
| Type |
ADAPTER |
| Application |
Electronic |
| Gender |
Male |
| Pins |
5P, 12p, 7P, 24P, 3P, 8P, 2P, 6P |
| Coding |
A / B / C / D / K / L / X / S / T Code |
| Temperature Range |
-25°C ~ +85°C |
| Rated Voltage |
DC60V AC50V |
| Contact Material |
Brass, gold plated |
| Mating cycle |
>100 times |
| Rated Current |
0.5A |
| Termination Style |
Solder Type / PCB Mount |
| Mounting Feature |
Front Mount / Back Mount / 4 Hole Flange |
| Mounting Type |
PCB Mount / Panel Mount / Cable |
| Number of Positions |
2 / 3 / 4 / 5 / 6 / 8 / 12 / 17 PIN |
Packaging & Delivery
M8 molded waterproof cable available in two packaging sizes: standard packaging with each piece in a PE bag inside a small carton, or customized packaging according to customer requirements.
