IP65 Panel Mount Connector GX aviation connector Solder Termination
100
MOQ
receive bargaining
Price
IP65 Panel Mount Connector GX aviation connector Solder Termination
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China ShenZhen
Brand Name: Rigoal
Certification: CE , ROSH , IP68
Model Number: assembly type
High Light:

Rigoal Panel Mount Connector

,

IP65 GX Panel Mount Connector

,

Solder Termination GX aviation connector

Payment & Shipping Terms
Packaging Details: 46x30x30
Delivery Time: 30work day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000
Specifications
Place Of Origin: Guangdong, China
Model Number: GX
Application: Audio & Video
Pin: 2 3 4 5 6 7 8 9 10 11 12 Pin
Rated Current(A): 5/7/10/12/15/20
Contact Material: Brass With Gold Plated
The Shell Material: Zinc Nickel-plated/Chrome-plated
Contact Resistance: 1/1.5/3/4/5
Termination: Solder
Type: ADAPTER, Panel Mount/Assembly/Molded Cable
Product Description

IP65 2 3 4 5 6 7 8 9 10 11 12 pin plug socket panel mount assembly molded cable GX series connector

GX12
Number of contact
2
3
4
5
6
7
Contact diameter
φ1.2
φ1.2
φ1.2
φ1.2
φ1.2
φ1.2
Rated current(A)
5
5
5
5
5
5
Rated voltage(AC,V)1min
200
125
125
125
125
125
Test voltage(AC,V)1min
1500
1500
1500
1500
1500
1500
Contact resistance(mΩ)
5
5
5
5
5
5
Insulation resistance
2000
2000
2000
2000
2000
2000
Diameter
φ0.8
φ0.8
φ0.8
φ0.8
φ0.8
φ0.8



GX16
Number of contact
2
3
4
5
6
7
8
9
10
Contact diameter
φ2.5
φ2.5
φ2.5
φ2.0
φ1.2
φ1.2
φ1.2
φ1.2
φ1.2
Rated current(A)
7
7
7
7
5
5
5
5
5
Rated voltage(AC,V)
220
220
125
125
125
125
125
125
125
Test voltage(AC,V)1min
1500
1500
1500
1500
1500
1500
1500
1500
1500
Contact resistance(mΩ)
3
3
3
4
5
5
5
5
5
Insulation resistance(mΩ)
2000
2000
2000
2000
2000
2000
2000
2000
2000
Diameter
φ1.4
φ1.4
φ1.4
φ1.2
φ0.8
φ0.8
φ0.8
φ0.8
φ0.8



GX19M
Number of contact
2
3
4
5
6
7
8
9
10
Contact diameter
φ3
φ3
φ3
φ3
φ2
φ2
φ1.5
φ1.5
φ1.5
Rated current(A)
10
7
7
7
5
5
5
5
5
Rated voltage(AC,V)
250
250
200
200
200
200
200
200
200
Test voltage(AC,V)1min
1500
1500
1500
1000
1000
1000
1000
1000
1000
Contact resistance(mΩ)
1
1
1
1.5
5
5
5
5
5
Insulation resistance(mΩ)
2000
2000
2000
2000
2000
2000
2000
2000
2000
Diameter
φ2.0
φ2.0
φ2.0
φ1.2
φ0.8
φ0.8
φ0.8
φ0.8
φ0.8



GX30M
Number of contact
2
3
4
5
6
7
8
10
Contact diameter
φ3.5
φ3.5
φ3.5
φ3.5
φ3.5
φ3.5
φ3.0
φ2.5
Rated current(A)
20
20
20
15
15
15
10
7
Rated voltage(AC,V)
500
500
500
400
400
400
250
250
Test voltage(AC,V)1min
1500
1500
1500
1000
1000
1000
1000
1000
Contact resistance(mΩ)
5
5
5
5
5
5
5
5
Insulation resistance(mΩ)
2000
2000
2000
2000
2000
2000
2000
2000
Diameter
φ0.5
φ0.5
φ0.5
φ0.5
φ0.5
φ0.5
φ0.5
φ0.5
Product introduction


GX16 series waterproof connector circular connectors socket

1.Coupling: Threaded
2.The shell material:
Zinc Nickel-plated/Chrome-plated
3.Insulator material: Bakelite
4.Contact material: Brass with gold plated
IP65 Panel Mount Connector GX aviation connector Solder Termination 0
IP65 Panel Mount Connector GX aviation connector Solder Termination 1




GX12/GX16/GX19/GX30


5.Termination: Solder
6.Mating cycle: 500 cycles
7.Temperature: -25°C~85°C
8.IP protection class: IP65


. GX series waterproof have Assembly and panel mount available connector .
. GX series circular aviation connector can be applied in microphone,keyboard aviation, navigation, computer, communications,
petroleum
exploration, navigation, anti-theft devices and so on.
Coding: A
Gender:Female and Male
Cable length: can be customized
IP65 Panel Mount Connector GX aviation connector Solder Termination 2
IP65 Panel Mount Connector GX aviation connector Solder Termination 3
IP65 Panel Mount Connector GX aviation connector Solder Termination 4
IP65 Panel Mount Connector GX aviation connector Solder Termination 5
IP65 Panel Mount Connector GX aviation connector Solder Termination 6
