Home /Products/M16 Circular Connector/IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application

IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application

100
MOQ
negotiable
Price
IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application
Features Gallery Product Description Request A Quote
Features
Specifications
Place Of Origin: Shen Zhen, China
Model Number: M16
Type: M16 Female Connector
Application: Automotive
Gender: Male
Pins:: 14P, 5P, 7P, 3P, 2P
Product Series: M16 Cable Connector
Insulation Resistance: ≥100 MΩ
Contact Resistance: ≤5mΩ
Basic Infomation
Brand Name: RIGOAL
Certification: CE,Rohs
Payment & Shipping Terms
Packaging Details: m16 3 2 7 5 14pin female ip67 waterproof panel mount solder connector 1.Our packaging:each pcs in one PE bag, then put in a small carton. 2.According to customer request.
Delivery Time: 14
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000
Product Description



IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application

IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application 0IP67 Waterproof Electrical Circular Cable Molded Assembly 5p/6p/7pin M16 Connectors For Sensor Application 1

Basic Product Information

Connector Series

M16 molded cable Connector

Gender

Male

Coding

A

Locking Type

Fix Screw

Mounting Type

Straight

Part No.

m16 waterproof connector

m16 cable connector

m16 circular connector



General Infomation
Standard IEC 61076-2-106 Insulation Resistance ≥100MΩ
Ambient Temperature - 40℃~+70℃/- 25℃~+70℃ Contact Resistance ≤5mΩ
Connector Insert BPT Shielding unvailable
Connector Contacts Brass with Gold Plated Seal/O-ring NBR/FKM
PCoupling Nut/Screw PA+GF Mating Endurance >500 cycles
IP Rating IP67/68/IP69K in locked condition Certificate ULS/CE/ROHS/IP67/REACH/IP68
